@flo71 ich hab das Script für den zweiten WR so angepasst, dass er erst regelt wenn der erste entweder am oberen oder unteren Limit angekommen ist, oder aber dass die geforderte Leistung höher ist als die, die gerade zur verfügung steht...
<xml xmlns="https://developers.google.com/blockly/xml">
<variables>
<variable id="?~:J:;gqC%-pt?=zNsH:">Sunrise</variable>
<variable id="UJ`JGN{Ezb$K7jJ[4P}j">Sunset</variable>
<variable id="BN!a@q$SEAU4^)xo:SRJ">maxSolarPower</variable>
<variable id="AcYpB0Ty+wVObL7=Y.a.">measuredPower</variable>
<variable id="1}Q0686mMw0ZGk)e+r?(">measuredSolarPower</variable>
<variable id="le#}gR{6G.yhW=x|6pS8">neededPower</variable>
<variable id="X-B3:`dA%wy5$?]at5W-">NeededPowerPercent</variable>
<variable id=":U;.Z4:pYNy(TwM9X-dL">storedNeededPower</variable>
<variable id="}s`y%Qd}~t2t(jU$8(ud">upperLimit</variable>
<variable id="P^1|W+9iVy?PgNp}9!.S">lowerLimit</variable>
<variable id=")2]D^Y|D:QS6S[A}9J=/">SolarLimit</variable>
</variables>
<block type="schedule" id="!P+uzJ#%y!_wHsKqo2~M" x="-443" y="-618">
<field name="SCHEDULE">*/20 * * * * *</field>
<statement name="STATEMENT">
<block type="variables_set" id="~v~t5u;a_q(#kb+E{(FH">
<field name="VAR" id="?~:J:;gqC%-pt?=zNsH:">Sunrise</field>
<value name="VALUE">
<block type="time_astro" id="Svgszky6QE2/10f8vck1">
<field name="TYPE">sunrise</field>
<field name="OFFSET">0</field>
</block>
</value>
<next>
<block type="variables_set" id="~/087{!i@]6[`rKxsw]j">
<field name="VAR" id="UJ`JGN{Ezb$K7jJ[4P}j">Sunset</field>
<value name="VALUE">
<block type="time_astro" id="BO/%++Qd.ktL4PfK.r3?">
<field name="TYPE">sunset</field>
<field name="OFFSET">0</field>
</block>
</value>
<next>
<block type="controls_if" id="xaOp|xXgB@BB44iq}cJ.">
<mutation else="1"></mutation>
<value name="IF0">
<block type="logic_operation" id="|K,B[pWUT`!LyJsB6,pK">
<field name="OP">AND</field>
<value name="A">
<block type="time_compare_ex" id="Y8n@Iqzd:%qZbp|#P_v^">
<mutation xmlns="http://www.w3.org/1999/xhtml" end_time="false" actual_time="true"></mutation>
<field name="USE_ACTUAL_TIME">TRUE</field>
<field name="OPTION">>=</field>
<value name="START_TIME">
<shadow type="text" id="]-0N3DkP*7?ghtYzXwX!">
<field name="TEXT">12:00</field>
</shadow>
<block type="variables_get" id="!,6PYgrHnSxh#Evn[Yie">
<field name="VAR" id="?~:J:;gqC%-pt?=zNsH:">Sunrise</field>
</block>
</value>
</block>
</value>
<value name="B">
<block type="time_compare_ex" id="qRYvI=rC7,D?`B=PV@^6">
<mutation xmlns="http://www.w3.org/1999/xhtml" end_time="false" actual_time="true"></mutation>
<field name="USE_ACTUAL_TIME">TRUE</field>
<field name="OPTION"><=</field>
<value name="START_TIME">
<shadow type="text">
<field name="TEXT">12:00</field>
</shadow>
<block type="variables_get" id="LMy)6-$QN(f3d9klxV`O">
<field name="VAR" id="UJ`JGN{Ezb$K7jJ[4P}j">Sunset</field>
</block>
</value>
</block>
</value>
</block>
</value>
<statement name="DO0">
<block type="variables_set" id="~p6WKGjCNU[UXfc{|$8|">
<field name="VAR" id="BN!a@q$SEAU4^)xo:SRJ">maxSolarPower</field>
<value name="VALUE">
<block type="math_number" id="Z(v(#cMkS]/o.,;iyE/|">
<field name="NUM">1500</field>
</block>
</value>
<next>
<block type="variables_set" id="Ih%sQzzK`!Ec=`tscEm-">
<field name="VAR" id="AcYpB0Ty+wVObL7=Y.a.">measuredPower</field>
<value name="VALUE">
<block type="get_value" id="E60zTd:yszZT-@pD[YB#">
<field name="ATTR">val</field>
<field name="OID">shelly.0.SHEM-3#E8DB84D68CFF#1.Total.InstantPower</field>
</block>
</value>
<next>
<block type="variables_set" id=":rlAB32E^@yPP9Jh?EMO">
<field name="VAR" id="1}Q0686mMw0ZGk)e+r?(">measuredSolarPower</field>
<value name="VALUE">
<block type="get_value" id="Q8pLDlgI~N(N2-6)X@Qu">
<field name="ATTR">val</field>
<field name="OID">opendtu.0.116180216966.ac.phase_1.power</field>
</block>
</value>
<next>
<block type="variables_set" id="t8-xB+K`%rr)x]%:Q5cN">
<field name="VAR" id="le#}gR{6G.yhW=x|6pS8">neededPower</field>
<value name="VALUE">
<block type="math_arithmetic" id="2FaDMR/kS5K9d!j=`dK3">
<field name="OP">ADD</field>
<value name="A">
<shadow type="math_number" id="2FEk%?jHI2)Hvf4}p|*;">
<field name="NUM">1</field>
</shadow>
<block type="variables_get" id="Z`YZ!4FileGG?5VwaP-/">
<field name="VAR" id="AcYpB0Ty+wVObL7=Y.a.">measuredPower</field>
</block>
</value>
<value name="B">
<shadow type="math_number" id="+10nRI6/x]hugF{/lmxM">
<field name="NUM">1</field>
</shadow>
<block type="variables_get" id="n0BqKn~p@qPw.Jvfrj,s">
<field name="VAR" id="1}Q0686mMw0ZGk)e+r?(">measuredSolarPower</field>
</block>
</value>
</block>
</value>
<next>
<block type="variables_set" id="$61h{3os=)%X-VEx9M:i">
<field name="VAR" id="X-B3:`dA%wy5$?]at5W-">NeededPowerPercent</field>
<value name="VALUE">
<block type="math_round" id="3$tH.4.P)ukPPcI4xw.A">
<field name="OP">ROUND</field>
<value name="NUM">
<shadow type="math_number" id="{D8W1ElJ#97Cg:]vDkM;">
<field name="NUM">3.1</field>
</shadow>
<block type="math_arithmetic" id="ju~9S8j-`0c/OF%2$7-o">
<field name="OP">MULTIPLY</field>
<value name="A">
<shadow type="math_number" id="6:p#t,*^;)z:Wb:@dc|3">
<field name="NUM">100</field>
</shadow>
</value>
<value name="B">
<shadow type="math_number" id=".fYZ,3H9RSS}:wD=%Bvk">
<field name="NUM">1</field>
</shadow>
<block type="math_arithmetic" id="Z9S-r-/8^FbCeq,[{ULB">
<field name="OP">DIVIDE</field>
<value name="A">
<shadow type="math_number" id="jul_lM$(9.yj`:ZH8}%@">
<field name="NUM">1</field>
</shadow>
<block type="variables_get" id="_mPBX.l-0%hNvWtND[z1">
<field name="VAR" id="le#}gR{6G.yhW=x|6pS8">neededPower</field>
</block>
</value>
<value name="B">
<shadow type="math_number" id="{Q+JfjzDv.)Z1KRbU*uv">
<field name="NUM">600</field>
</shadow>
<block type="variables_get" id="M!sN^/9!7$b}.ru.lqgC">
<field name="VAR" id="BN!a@q$SEAU4^)xo:SRJ">maxSolarPower</field>
</block>
</value>
</block>
</value>
</block>
</value>
</block>
</value>
<next>
<block type="variables_set" id="g3gA+F5X4*$4x2),%sJV">
<field name="VAR" id=":U;.Z4:pYNy(TwM9X-dL">storedNeededPower</field>
<value name="VALUE">
<block type="get_value" id="7wbrC,7l;@ahCGcw2/pL">
<field name="ATTR">val</field>
<field name="OID">0_userdata.0.PV-Anlage.storedNeededPower</field>
</block>
</value>
<next>
<block type="variables_set" id="2KI]WdQd`0MzEf%mOPaL">
<field name="VAR" id="}s`y%Qd}~t2t(jU$8(ud">upperLimit</field>
<value name="VALUE">
<block type="math_round" id="Ha.~N]M`[1eWboby_aYe">
<field name="OP">ROUND</field>
<value name="NUM">
<shadow type="math_number" id=":C/cpWh)P`-jK9}]IN*4">
<field name="NUM">3.1</field>
</shadow>
<block type="math_arithmetic" id="v}v!|Jkv3JHVqQR7poM0">
<field name="OP">ADD</field>
<value name="A">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
<block type="variables_get" id="{dg*rTfc(I5I1PoYYN;l">
<field name="VAR" id=":U;.Z4:pYNy(TwM9X-dL">storedNeededPower</field>
</block>
</value>
<value name="B">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
<block type="math_arithmetic" id="#Aa[sC!ija_TtL9Go*jl">
<field name="OP">MULTIPLY</field>
<value name="A">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
<block type="variables_get" id="?YS@_}6Hup[`ZsLR!Z45">
<field name="VAR" id=":U;.Z4:pYNy(TwM9X-dL">storedNeededPower</field>
</block>
</value>
<value name="B">
<shadow type="math_number" id="YxGb?xk[MY37)!7O-Cqe">
<field name="NUM">0.05</field>
</shadow>
</value>
</block>
</value>
</block>
</value>
</block>
</value>
<next>
<block type="variables_set" id="+KJ71_Z(eLN.a(uoEuci">
<field name="VAR" id="P^1|W+9iVy?PgNp}9!.S">lowerLimit</field>
<value name="VALUE">
<block type="math_round" id="=HYNg!vGE)^Z7m{+e$cs">
<field name="OP">ROUND</field>
<value name="NUM">
<shadow type="math_number" id="|d.50MyF$Zxnn(B]!gq~">
<field name="NUM">3.1</field>
</shadow>
<block type="math_arithmetic" id="?8HAOa[X,LM#h`p]lLc4">
<field name="OP">MINUS</field>
<value name="A">
<shadow type="math_number" id="(8p!3BSrd)N0m`PVj}cd">
<field name="NUM">1</field>
</shadow>
<block type="variables_get" id="?$cU!rsg;wkU}CP.VsR.">
<field name="VAR" id=":U;.Z4:pYNy(TwM9X-dL">storedNeededPower</field>
</block>
</value>
<value name="B">
<shadow type="math_number" id="@kP8*eoC!D4/Wa?%grKM">
<field name="NUM">1</field>
</shadow>
<block type="math_arithmetic" id="D$_kryX`Gb5eu$gnYS_q">
<field name="OP">MULTIPLY</field>
<value name="A">
<shadow type="math_number">
<field name="NUM">1</field>
</shadow>
<block type="variables_get" id="nrL6t1UCC{jy1*U[O|Xq">
<field name="VAR" id=":U;.Z4:pYNy(TwM9X-dL">storedNeededPower</field>
</block>
</value>
<value name="B">
<shadow type="math_number" id="||~-FC.nb3oU=fuLJzw}">
<field name="NUM">0.1</field>
</shadow>
</value>
</block>
</value>
</block>
</value>
</block>
</value>
<next>
<block type="debug" id="8cGY=ms*^/Fbn#Cde4/e">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text">
<field name="TEXT">test</field>
</shadow>
<block type="text_join" id="QUQf.~7J|ziuD3sLdl)|">
<mutation items="2"></mutation>
<value name="ADD0">
<block type="text" id="lGPf[Ci!QdAF4j#Bn34-">
<field name="TEXT">Sonnenaufgang; </field>
</block>
</value>
<value name="ADD1">
<block type="variables_get" id="kwmbl:u%6-!)]lE{Bhdj">
<field name="VAR" id="?~:J:;gqC%-pt?=zNsH:">Sunrise</field>
</block>
</value>
</block>
</value>
<next>
<block type="debug" id="yaFK]t~sZKg}j1WzH!TL">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text">
<field name="TEXT">test</field>
</shadow>
<block type="text_join" id="g_%Dq-ksE!p;Tib-dWoB">
<mutation items="2"></mutation>
<value name="ADD0">
<block type="text" id="(bZZUaTT0bt~IQ|a~%#R">
<field name="TEXT">Sonnenuntergang; </field>
</block>
</value>
<value name="ADD1">
<block type="variables_get" id="weuYcyZ5+:mfnpSK9UiP">
<field name="VAR" id="UJ`JGN{Ezb$K7jJ[4P}j">Sunset</field>
</block>
</value>
</block>
</value>
<next>
<block type="debug" id="1|f1K~GhCe(a;/q4o_X]">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text">
<field name="TEXT">test</field>
</shadow>
<block type="text_join" id="2Zo2{I0w6J%`$2:qEY1l">
<mutation items="2"></mutation>
<value name="ADD0">
<block type="text" id="+YI.VRyx;em.YT$D(|bs">
<field name="TEXT">Istwert: </field>
</block>
</value>
<value name="ADD1">
<block type="variables_get" id="z%3ACfZd0~)KLgj0p}%@">
<field name="VAR" id=":U;.Z4:pYNy(TwM9X-dL">storedNeededPower</field>
</block>
</value>
</block>
</value>
<next>
<block type="debug" id="r+xN[i`4xS-M`OYDBpb.">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text">
<field name="TEXT">test</field>
</shadow>
<block type="text_join" id="(f(78JM#Hy0@?Z0hJe~l">
<mutation items="2"></mutation>
<value name="ADD0">
<block type="text" id="~}`O(MW.TU:J%_oS)#Xu">
<field name="TEXT">obere Grenze: </field>
</block>
</value>
<value name="ADD1">
<block type="variables_get" id=",vBoJg7x{3!@v.c5w4q]">
<field name="VAR" id="}s`y%Qd}~t2t(jU$8(ud">upperLimit</field>
</block>
</value>
</block>
</value>
<next>
<block type="debug" id="qBNh2:P3U}F#$|$6FZFn">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text" id="2kPK8(t-SdR9TZvb.%-l">
<field name="TEXT">test</field>
</shadow>
<block type="text_join" id="}cq5v9RJT$55w(=?6BX)">
<mutation items="2"></mutation>
<value name="ADD0">
<block type="text" id="*q^TTVgJ+?:b!z,x/S;V">
<field name="TEXT">untere Grenze: </field>
</block>
</value>
<value name="ADD1">
<block type="variables_get" id="Vh$)4$K%:ZHW:~MiMXet">
<field name="VAR" id="P^1|W+9iVy?PgNp}9!.S">lowerLimit</field>
</block>
</value>
</block>
</value>
<next>
<block type="debug" id="k}*+@}8y%^u*6nB1JGm^">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text">
<field name="TEXT">test</field>
</shadow>
<block type="text_join" id="9O/.cB+R0J#M=YHuIJn?">
<mutation items="2"></mutation>
<value name="ADD0">
<block type="text" id="3Uv-x,Irz%wnP{oXU!s^">
<field name="TEXT">benötigte Power in Prozent:</field>
</block>
</value>
<value name="ADD1">
<block type="variables_get" id="T);Yxf;X[xS0z_7}_YkI">
<field name="VAR" id="X-B3:`dA%wy5$?]at5W-">NeededPowerPercent</field>
</block>
</value>
</block>
</value>
<next>
<block type="controls_if" id="//Rx),f%pyif!qW8O/?G">
<mutation elseif="1" else="1"></mutation>
<value name="IF0">
<block type="logic_operation" id="6|n{EZ*g-L?wwMuw~`pt">
<field name="OP">AND</field>
<value name="A">
<block type="logic_compare" id="@s)ep$AZC}nn4%[Y{zXv">
<field name="OP">GTE</field>
<value name="A">
<block type="variables_get" id="rLGQIwoD@(-[)i.@Gek1">
<field name="VAR" id="X-B3:`dA%wy5$?]at5W-">NeededPowerPercent</field>
</block>
</value>
<value name="B">
<block type="math_number" id="i.8)/]r6EY5E@{+61}ch">
<field name="NUM">100</field>
</block>
</value>
</block>
</value>
<value name="B">
<block type="logic_compare" id="M%7gn=%*6!Oo0Iy!N0HE">
<field name="OP">EQ</field>
<value name="A">
<block type="variables_get" id="FPBUa4}8MCdw~u2(u=Z4">
<field name="VAR" id=":U;.Z4:pYNy(TwM9X-dL">storedNeededPower</field>
</block>
</value>
<value name="B">
<block type="math_number" id="])#t~DUCT78?qe_~1/X)">
<field name="NUM">100</field>
</block>
</value>
</block>
</value>
</block>
</value>
<statement name="DO0">
<block type="debug" id="_|aD2Z`JU`?BoQCCcfTz">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text" id="wcNA/`cj2DUcJLr26^bd">
<field name="TEXT">keine Änderung, Wert ist gleich gespeichertem Wert</field>
</shadow>
</value>
</block>
</statement>
<value name="IF1">
<block type="logic_operation" id="4WJuW,40dOlCCnG8!=A(">
<field name="OP">OR</field>
<value name="A">
<block type="logic_compare" id="0U*fZT58L0uKFJsD)N{;">
<field name="OP">GT</field>
<value name="A">
<block type="variables_get" id="%=U`G7.6z`w:8|:XtgTI">
<field name="VAR" id="X-B3:`dA%wy5$?]at5W-">NeededPowerPercent</field>
</block>
</value>
<value name="B">
<block type="variables_get" id="IE{(_NPVQP{:.^rxbG?4">
<field name="VAR" id="}s`y%Qd}~t2t(jU$8(ud">upperLimit</field>
</block>
</value>
</block>
</value>
<value name="B">
<block type="logic_compare" id="7GGwP6lHcmy!ILxZJvYk">
<field name="OP">LT</field>
<value name="A">
<block type="variables_get" id="EN^7brshgWEicI7V4)C!">
<field name="VAR" id="X-B3:`dA%wy5$?]at5W-">NeededPowerPercent</field>
</block>
</value>
<value name="B">
<block type="variables_get" id="7B.88d1a^Hr`R-b6!iMZ">
<field name="VAR" id="P^1|W+9iVy?PgNp}9!.S">lowerLimit</field>
</block>
</value>
</block>
</value>
</block>
</value>
<statement name="DO1">
<block type="controls_if" id="P8/_4.KJ/zZ6qh9iBh+o">
<mutation else="1"></mutation>
<value name="IF0">
<block type="logic_compare" id="mk*xKT^,LdqKZpmRr}r4">
<field name="OP">LTE</field>
<value name="A">
<block type="variables_get" id=".d_KP;p/?wytr_{S7(db">
<field name="VAR" id="le#}gR{6G.yhW=x|6pS8">neededPower</field>
</block>
</value>
<value name="B">
<block type="variables_get" id="R!EQmKR0*lP1iR`NTG%f">
<field name="VAR" id="BN!a@q$SEAU4^)xo:SRJ">maxSolarPower</field>
</block>
</value>
</block>
</value>
<statement name="DO0">
<block type="variables_set" id="v_^pc%4YAqueF4@xp/Ph">
<field name="VAR" id=")2]D^Y|D:QS6S[A}9J=/">SolarLimit</field>
<value name="VALUE">
<block type="variables_get" id="rba!2I;EQyijkPfjo!Ze">
<field name="VAR" id="X-B3:`dA%wy5$?]at5W-">NeededPowerPercent</field>
</block>
</value>
<next>
<block type="update" id="E7HJvqAC,*BNAxN~e8sd">
<mutation xmlns="http://www.w3.org/1999/xhtml" delay_input="false"></mutation>
<field name="OID">0_userdata.0.PV-Anlage.storedNeededPower</field>
<field name="WITH_DELAY">FALSE</field>
<value name="VALUE">
<block type="variables_get" id="hR1[WimPbd@1ICN+UAdn">
<field name="VAR" id="X-B3:`dA%wy5$?]at5W-">NeededPowerPercent</field>
</block>
</value>
</block>
</next>
</block>
</statement>
<statement name="ELSE">
<block type="variables_set" id="iqqD`P-h34,:2q7p$CH|">
<field name="VAR" id=")2]D^Y|D:QS6S[A}9J=/">SolarLimit</field>
<value name="VALUE">
<block type="math_number" id="dowAhu.+=iz#Wc-F]p:X">
<field name="NUM">100</field>
</block>
</value>
<next>
<block type="update" id="*?5=;cANP)NJ|KuX_[PF">
<mutation xmlns="http://www.w3.org/1999/xhtml" delay_input="false"></mutation>
<field name="OID">0_userdata.0.PV-Anlage.storedNeededPower</field>
<field name="WITH_DELAY">FALSE</field>
<value name="VALUE">
<block type="math_number" id="7vXqNl1zb}n*oh6q3:]4">
<field name="NUM">100</field>
</block>
</value>
</block>
</next>
</block>
</statement>
<next>
<block type="controls_if" id="]^/I[vJo!sr5LpkbcFB!">
<value name="IF0">
<block type="logic_compare" id="%50d#)U*~RScC:F-kp{g">
<field name="OP">LTE</field>
<value name="A">
<block type="variables_get" id="KVYNgaA$~@zFf4U(-2G(">
<field name="VAR" id=")2]D^Y|D:QS6S[A}9J=/">SolarLimit</field>
</block>
</value>
<value name="B">
<block type="math_number" id="!0pj`kNb_!ZOVov*^)[3">
<field name="NUM">4</field>
</block>
</value>
</block>
</value>
<statement name="DO0">
<block type="variables_set" id="/4+e9gEK~pdujzM|}ksi">
<field name="VAR" id=")2]D^Y|D:QS6S[A}9J=/">SolarLimit</field>
<value name="VALUE">
<block type="math_number" id="c+YG2dsZvm-}l6dXt[1Z">
<field name="NUM">5</field>
</block>
</value>
</block>
</statement>
<next>
<block type="controls_if" id="ZH?n)}/A8xDqvLu;mM3m">
<mutation else="1"></mutation>
<value name="IF0">
<block type="logic_operation" id="vVy#@8N({zRaYhlMew]c">
<field name="OP">OR</field>
<value name="A">
<block type="logic_compare" id="PIGb)h}(L;=:AD;5r=W$">
<field name="OP">LTE</field>
<value name="A">
<block type="get_value" id="Hn,:c1}lRncb$M*c37T[">
<field name="ATTR">val</field>
<field name="OID">0_userdata.0.PV-Anlage.Solarlimit_HM400.Solarlimit_HM400</field>
</block>
</value>
<value name="B">
<block type="math_number" id="O/l%Uh0A@?HPfD;/4eRW">
<field name="NUM">5</field>
</block>
</value>
</block>
</value>
<value name="B">
<block type="logic_operation" id="x8],WeAvz)P5RbWxBqKU">
<field name="OP">OR</field>
<value name="A">
<block type="logic_compare" id="D1Vr-[UHVwz,0UMcxf~t">
<field name="OP">GTE</field>
<value name="A">
<block type="get_value" id="*^o)uk]A48Tjk%pvj2pB">
<field name="ATTR">val</field>
<field name="OID">0_userdata.0.PV-Anlage.Solarlimit_HM400.Solarlimit_HM400</field>
</block>
</value>
<value name="B">
<block type="math_number" id="az|/|Fl[JpJ{rB83ed[p">
<field name="NUM">100</field>
</block>
</value>
</block>
</value>
<value name="B">
<block type="logic_compare" id="1f.~}_NZHFWHi$U;Bl[E">
<field name="OP">LT</field>
<value name="A">
<block type="get_value" id="o%XYKF2zkxK+dE|3E%-_">
<field name="ATTR">val</field>
<field name="OID">opendtu.0.112183217812.ac.phase_1.power</field>
</block>
</value>
<value name="B">
<block type="get_value" id="uM~uo~N[nRQ?i9!fzRA!">
<field name="ATTR">val</field>
<field name="OID">opendtu.0.112183217812.power_control.current_limit_absolute</field>
</block>
</value>
</block>
</value>
</block>
</value>
</block>
</value>
<statement name="DO0">
<block type="control" id="W+gr)Q`C;VMjG:,mB)8r">
<mutation xmlns="http://www.w3.org/1999/xhtml" delay_input="false"></mutation>
<field name="OID">opendtu.0.116180216966.power_control.limit_nonpersistent_relative</field>
<field name="WITH_DELAY">FALSE</field>
<value name="VALUE">
<block type="variables_get" id="0O[l*@b$eWz(z6Nj5;8Z">
<field name="VAR" id=")2]D^Y|D:QS6S[A}9J=/">SolarLimit</field>
</block>
</value>
<next>
<block type="debug" id="4(mO4hae0d8|yCEDlMj~">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text" id="GhK9E*i9z*IoFuBKSaq1">
<field name="TEXT">test</field>
</shadow>
<block type="text_join" id="K$7:Tw;%Pm?f$3/:xV?V">
<mutation items="2"></mutation>
<value name="ADD0">
<block type="text" id="tzX795?CuQ=.SGL`i!ns">
<field name="TEXT">gesetztes Limit: </field>
</block>
</value>
<value name="ADD1">
<block type="variables_get" id="`hpd|~6gnaa1#A:#I^ku">
<field name="VAR" id=")2]D^Y|D:QS6S[A}9J=/">SolarLimit</field>
</block>
</value>
</block>
</value>
</block>
</next>
</block>
</statement>
<statement name="ELSE">
<block type="debug" id="Pv3KiYZaGuo2FdU}gjig">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text" id="t2%tFy.G9l;?j^VyEMCa">
<field name="TEXT">keine Änderung</field>
</shadow>
</value>
</block>
</statement>
</block>
</next>
</block>
</next>
</block>
</statement>
<statement name="ELSE">
<block type="debug" id="k-_yI!1YR}Cw@^zA*2By">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text" id="pOzzR,#7b~P,=jhm/QLz">
<field name="TEXT">keine Änderung</field>
</shadow>
</value>
</block>
</statement>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</next>
</block>
</statement>
<statement name="ELSE">
<block type="debug" id="6hv2w66u%V}c3Ij`Q?pi">
<field name="Severity">log</field>
<value name="TEXT">
<shadow type="text" id="LmPU])Tk80,#%40`K:m4">
<field name="TEXT">Zeit ist außerhalb der Reglungszeit.</field>
</shadow>
</value>
</block>
</statement>
</block>
</next>
</block>
</next>
</block>
</statement>
</block>
</xml>
