Ich habe die Firmware hier installiert:
Z-Stack_3.x.0
Der Stick wird jetzt so erkannt:
pi@raspberrypi:~ $ ls -la /dev/serial/by-id
insgesamt 0
drwxr-xr-x 2 root root 60 17. Mai 16:12 .
drwxr-xr-x 4 root root 80 17. Mai 16:12 ..
lrwxrwxrwx 1 root root 13 17. Mai 16:12 usb-ITead_Sonoff_Zigbee_3.0_USB_Dongle_Plus_24523334e35fec1192ca385f25bfaa52-if00-port0 -> ../../ttyUSB0
Und eingestellt ist der so:
Das Log sagt folgendes:
2022-05-17 16:20:35.935 - info: host.raspberrypi instance system.adapter.zigbee.0 terminated with code 11 (ADAPTER_REQUESTED_TERMINATION)
2022-05-17 16:20:38.402 - info: host.raspberrypi instance system.adapter.zigbee.0 started with pid 1960
2022-05-17 16:20:38.402 - info: host.raspberrypi instance system.adapter.zigbee.0 started with pid 1960
2022-05-17 16:20:40.790 - debug: zigbee.0 (1960) Redis Objects: Use Redis connection: 127.0.0.1:9001
2022-05-17 16:20:40.847 - debug: zigbee.0 (1960) Objects client ready ... initialize now
2022-05-17 16:20:40.850 - debug: zigbee.0 (1960) Objects create System PubSub Client
2022-05-17 16:20:40.852 - debug: zigbee.0 (1960) Objects create User PubSub Client
2022-05-17 16:20:40.911 - debug: zigbee.0 (1960) Objects client initialize lua scripts
2022-05-17 16:20:40.918 - debug: zigbee.0 (1960) Objects connected to redis: 127.0.0.1:9001
2022-05-17 16:20:40.953 - debug: zigbee.0 (1960) Redis States: Use Redis connection: 127.0.0.1:9000
2022-05-17 16:20:40.971 - debug: zigbee.0 (1960) States create System PubSub Client
2022-05-17 16:20:40.972 - debug: zigbee.0 (1960) States create User PubSub Client
2022-05-17 16:20:41.012 - debug: zigbee.0 (1960) States connected to redis: 127.0.0.1:9000
2022-05-17 16:20:41.123 - debug: zigbee.0 (1960) Plugin sentry Initialize Plugin (enabled=true)
2022-05-17 16:20:41.492 - info: zigbee.0 (1960) starting. Version 1.6.18 in /opt/iobroker/node_modules/iobroker.zigbee, node: v14.19.2, js-controller: 4.0.23
2022-05-17 16:20:41.534 - debug: zigbee.0 (1960) Using zigbee-herdsman with settings: {"network":{"panID":6754,"channelList":[11],"networkKey":[1,3,5,7,9,11,13,15,0,2,4,6,8,10,12,13],"extenedPanID":[88,242,222,188,90,137,132,21]},"databasePath":"/opt/iobroker/iobroker-data/zigbee_0/shepherd.db","backupPath":"/opt/iobroker/iobroker-data/zigbee_0/nvbackup.json","serialPort":{"baudRate":115200,"rtscts":false,"path":"/dev/serial/by-id/usb-ITead_Sonoff_Zigbee_3.0_USB_Dongle_Plus_24523334e35fec1192ca385f25bfaa52-if00-port0","adapter":"zstack"},"adapter":{"forceStartWithInconsistentAdapterConfiguration":false}}
2022-05-17 16:20:41.591 - info: zigbee.0 (1960) Starting Zigbee npm ...
2022-05-17 16:20:41.592 - debug: zigbee.0 (1960) Starting zigbee-herdsman...
2022-05-17 16:20:42.096 - debug: zigbee.0 (1960) Backup /opt/iobroker/iobroker-data/zigbee_0/backup_2022_05_17-16_20_41.tar.gz success
2022-05-17 16:20:42.105 - info: zigbee.0 (1960) Installed Version: iobroker.zigbee@1.6.18
2022-05-17 16:20:40.790 - debug: zigbee.0 (1960) Redis Objects: Use Redis connection: 127.0.0.1:9001
2022-05-17 16:20:40.847 - debug: zigbee.0 (1960) Objects client ready ... initialize now
2022-05-17 16:20:40.850 - debug: zigbee.0 (1960) Objects create System PubSub Client
2022-05-17 16:20:40.852 - debug: zigbee.0 (1960) Objects create User PubSub Client
2022-05-17 16:20:40.911 - debug: zigbee.0 (1960) Objects client initialize lua scripts
2022-05-17 16:20:40.918 - debug: zigbee.0 (1960) Objects connected to redis: 127.0.0.1:9001
2022-05-17 16:20:40.953 - debug: zigbee.0 (1960) Redis States: Use Redis connection: 127.0.0.1:9000
2022-05-17 16:20:40.971 - debug: zigbee.0 (1960) States create System PubSub Client
2022-05-17 16:20:40.972 - debug: zigbee.0 (1960) States create User PubSub Client
2022-05-17 16:20:41.012 - debug: zigbee.0 (1960) States connected to redis: 127.0.0.1:9000
2022-05-17 16:20:41.123 - debug: zigbee.0 (1960) Plugin sentry Initialize Plugin (enabled=true)
2022-05-17 16:20:41.492 - info: zigbee.0 (1960) starting. Version 1.6.18 in /opt/iobroker/node_modules/iobroker.zigbee, node: v14.19.2, js-controller: 4.0.23
2022-05-17 16:20:41.534 - debug: zigbee.0 (1960) Using zigbee-herdsman with settings: {"network":{"panID":6754,"channelList":[11],"networkKey":[1,3,5,7,9,11,13,15,0,2,4,6,8,10,12,13],"extenedPanID":[88,242,222,188,90,137,132,21]},"databasePath":"/opt/iobroker/iobroker-data/zigbee_0/shepherd.db","backupPath":"/opt/iobroker/iobroker-data/zigbee_0/nvbackup.json","serialPort":{"baudRate":115200,"rtscts":false,"path":"/dev/serial/by-id/usb-ITead_Sonoff_Zigbee_3.0_USB_Dongle_Plus_24523334e35fec1192ca385f25bfaa52-if00-port0","adapter":"zstack"},"adapter":{"forceStartWithInconsistentAdapterConfiguration":false}}
2022-05-17 16:20:41.591 - info: zigbee.0 (1960) Starting Zigbee npm ...
2022-05-17 16:20:41.592 - debug: zigbee.0 (1960) Starting zigbee-herdsman...
2022-05-17 16:20:42.096 - debug: zigbee.0 (1960) Backup /opt/iobroker/iobroker-data/zigbee_0/backup_2022_05_17-16_20_41.tar.gz success
2022-05-17 16:20:42.105 - info: zigbee.0 (1960) Installed Version: iobroker.zigbee@1.6.18
2022-05-17 16:21:02.289 - error: zigbee.0 (1960) Starting zigbee-herdsman problem : "Failed to connect to the adapter (Error: SRSP - SYS - ping after 6000ms)"
2022-05-17 16:21:02.290 - error: zigbee.0 (1960) Failed to start Zigbee
2022-05-17 16:21:02.290 - error: zigbee.0 (1960) Error herdsman start
2022-05-17 16:21:02.289 - error: zigbee.0 (1960) Starting zigbee-herdsman problem : "Failed to connect to the adapter (Error: SRSP - SYS - ping after 6000ms)"
2022-05-17 16:21:02.290 - error: zigbee.0 (1960) Failed to start Zigbee
2022-05-17 16:21:02.290 - error: zigbee.0 (1960) Error herdsman start
2022-05-17 16:21:12.293 - info: zigbee.0 (1960) Try to reconnect. 1 attempts left
2022-05-17 16:21:12.295 - info: zigbee.0 (1960) Starting Zigbee npm ...
2022-05-17 16:21:12.296 - debug: zigbee.0 (1960) Starting zigbee-herdsman...
2022-05-17 16:21:12.319 - info: zigbee.0 (1960) Installed Version: iobroker.zigbee@1.6.18
2022-05-17 16:21:12.564 - error: zigbee.0 (1960) Starting zigbee-herdsman problem : "Error while opening serialport 'Error: Error Resource temporarily unavailable Cannot lock port'"
2022-05-17 16:21:12.565 - error: zigbee.0 (1960) Failed to start Zigbee
2022-05-17 16:21:12.566 - error: zigbee.0 (1960) Error herdsman start
2022-05-17 16:21:12.293 - info: zigbee.0 (1960) Try to reconnect. 1 attempts left
2022-05-17 16:21:12.295 - info: zigbee.0 (1960) Starting Zigbee npm ...
2022-05-17 16:21:12.296 - debug: zigbee.0 (1960) Starting zigbee-herdsman...
2022-05-17 16:21:12.319 - info: zigbee.0 (1960) Installed Version: iobroker.zigbee@1.6.18
2022-05-17 16:21:12.564 - error: zigbee.0 (1960) Starting zigbee-herdsman problem : "Error while opening serialport 'Error: Error Resource temporarily unavailable Cannot lock port'"
2022-05-17 16:21:12.565 - error: zigbee.0 (1960) Failed to start Zigbee
2022-05-17 16:21:12.566 - error: zigbee.0 (1960) Error herdsman start
Das Flashen wurde mit einer erfolgreichen Meldung beendet. Kann man das sonst noch irgendwie kontrollieren?
